Motor Features
1. Constructed with replaceable cartridge brushes to ensure a longer motor life.
2. Both front and rear end bells can be customized to fit your OEM applications.
3. Single or double shaft extension is available.
4. Quality windings and dedicated workmanships to guarantee good motor performance.
5. EMC certificate is available upon request.
6. Frequently applied to electric motor driven devices such as wheelchairs, power tools, conveyors and door openers.
Applications
1. Wheelchairs
2. Power tools
3. Small size conveyors
4. Door openers
5. Industrial control facilities
| Voltage Range | 12 & 24 VDC (240VDC also available) |
| Power Output Range | 30-190 W |
| Speed Range | 1000-6000 RPM |
| Operational Temperature | –20℃～+40℃ |
| Insulation Class | F (contact us for class B) |
| Housing Type | Enclosed (ventilated also available） |
| Part Number | Voltage | No load Current | No load Speed | Torque | Rated Current | Rated Speed | Rated Power | Length |
| Units | V | A | RPM | Nm | A | RPM | W | mm |
| 60ZYT009 | 36 | 0.3 | 4500 | 0.3 | 3.3 | 3900 | 161 | 120 |
| 60ZYT010 | 60 | 0.3 | 5000 | 0.35 | 3.3 | 4400 | 161 | 127 |
| 63ZYT015 | 90 | 0.15 | 3470 | 0.25 | 1.3 | 2784 | 73 | 100 |
| 63ZYT030 | 24 | 0.6 | 4000 | 0.4 | 7 | 3000 | 126 | 100 |
