Motor Features
1. More working voltage options to offer additional design freedom for your engineers.
2. Built with quality windings andrare earth magnets to improve motor performance.
3. Flexible motor body length is available depending on your specific application.
4. Replaceable cartridge brushes to prolong motor life.
5. Commonly applied to door openers, seat-moving motors in cars and pumping equipment.
Applications
1. Cleaning equipment
2. Tarping systems for trucks
3. Batteries-powered special vehicles
4. Material handling system
| Voltage Range | 12 & 24 VDC (240VDC also available) |
| Power Output Range | 100-550 W |
| Speed Range | 1000-6000 RPM |
| Operational Temperature | –20℃～+40℃ |
| Insulation Class | F (contact us for class B) |
| Housing Type | Enclosed (ventilated also available） |
| Part Number | Voltage | No load Current | No load Speed | Torque | Rated Current | Rated Speed | Rated Power | Length |
| Units | V | A | RPM | Nm | A | RPM | W | mm |
| 80ZYT001 | 12 | 3.5 | 3600 | 0.4 | 16.5 | 3000 | 126 | 146.5 |
| 80ZYT002 | 24 | 1.6 | 3539 | 0.5 | 10 | 3373 | 177 | 173.8 |
| 80ZYT025 | 12 | 6.5 | 4500 | 0.6 | 29.9 | 3558 | 224 | 121 |
| 80ZYT039 | 90 | 0.8 | 4600 | 1.2 | 7.5 | 4100 | 515 | 173.8 |
