Motor Features
1. Commutators are finely machined and inspected before the complete motor assembly is prepared to avoid any sparking or extra noise while the electric motor is running.
2. Closed-type construction ensures the motor can handle outdoor operation.
3. Stabilized performance with a large output torque.
4. Optional extended shaft and frontend bell.
5. Commonly installed in seeders, blenders as well as watering pumps.
Applications
1. Turntables
2. Pick and place
3. Watering pumps
4. Garage door openers
| Voltage Range | 12 & 24 VDC (240VDC also available) |
| Power Output Range | 30-190 W |
| Speed Range | 1000-6000 RPM |
| Operational Temperature | –20℃～+40℃ |
| Insulation Class | F (contact us for class B) |
| Housing Type | Enclosed (ventilated also available） |
| Part Number | Voltage | No load Current | No load Speed | Torque | Rated Current | Rated Speed | Rated Power | Length |
| Units | VDC | A | RPM | Nm | A | RPM | W | mm |
| 76ZYT002 | 24 | 1.5 | 3850 | 0.4 | 9 | 3200 | 134 | 133.5 |
| 76ZYT005 | 12 | 0.9 | 3200 | 0.12 | 5 | 3088 | 39 | 115 |
| 76ZYT007 | 12 | 2.6 | 3850 | 0.4 | 16 | 3200 | 134 | 133.5 |
| 76ZYT008 | 24 | 0.9 | 3200 | 0.12 | 2.3 | 3088 | 39 | 115 |
