Motor Features
1. The DC geared motor's worm gear can be customized to achieve maximum output torque.
2. The electric motor's speed ranges offer more options to application engineers.
3. The DC motor has a higher transmission efficiency and longer servicing life.
4. Delrin gears are available for reduced motor noise.
5. Nominal working voltage options are available to help you with your R&D projects.
6. Widely applied to the marine facilities and door openers.
Applications
1. Scooters
2. Golf carts
3. Small machinery
4. Where reduced speed and increased torque are required
| Gearbox Housing | Ruggedised die-cast Aluminum | |||
| Worm Gear Material | Bronze,steel or glass-filled plastic | |||
| Lubrication | Grease lubricated & sealed | |||
| Gearbox Output Bearing Type | High quality ball bearings | |||
| Insulation Class | F (contact us for class B) | |||
| Brush Type | Integral or removable | |||
| Ambient Operating Temperature | -20℃ to +40℃ | |||
| Motor Size | worm wheel material | Gear Ratio | Speed range | Output Shaft Type | ||||
| 90ZYT、100ZYT、110ZYT | Delrin、Bronze | 25:1 | 125-300 | Customized | ||||
| 90ZYT、100ZYT、110ZYT | Delrin、Bronze | 30:1 | 60-150 | Customized | ||||
| 90ZYT、100ZYT、110ZYT | Delrin、Bronze | 60:1 | 50-125 | Customized | ||||
| 90ZYT、100ZYT、110ZYT | Delrin、Bronze | 75:1 | 30-75 | Customized | ||||
